Features

The standard SC-300 features dual smoke elements with woodchip boxes to produce the maximum amount of smoke. An optional feature is a steam system that replaces the right smoke element in the cabinet. The standard control allows the ability to select any combination of heat, smoke, and steam,
if applicable.

SC-300 specifications

• Dimensions | 61 1/4”t x 24 3/4”w x 32 1/2”d
• Weight | 300 lbs
• Temperature Range | 80° – 325°F (27° – 163°C)
• Product Racks | 5 – 18” x 26” nickel chrome plated
• Electrical | 208 volt AC, 60 hertz, 1-phase, 40 amp or 240 volt AC, 60 hertz, 1-phase, 40 amp or 230 volt AC, 50 hertz, 1-phase, 40 amp
• Electric Heating Elements | 2 – 2,250 watt
• Venting | Type 1 Canopy Hood required. See pages 18-19 for details
